Removal and replacement: Scanner control board (SCB) cover
●
Introduction
●
Step 1: Remove the scanner control board (SCB) cover
●
Step 2: Unpack the replacement assembly
●
Step 3: Install the SCB cover
Introduction
This document provides the procedures to remove and replace the scanner control board (SCB) cover.
Before performing service
Turn the printer power o
◦
Disconnect the power cable.
WARNING! To avoid damage to the printer, turn the printer o, wait 30 seconds, and then remove the
power cable before attempting to service the printer.
Use the table below to identify the correct part number for your printer. To order the part, go to
www.hp.com/buy/parts.
Scanner control board (SCB) cover part number
G1W39-67936 SCB cover
Required tools
●
#10 Torx driver with a 152 mm (6 in) shaft and magnetized tip.
After performing service
Turn the printer power on
◦
Connect the power cable.
◦
Use the power switch to turn the power on.
Post service test
No post service test are available for this assembly.
Step 1: Remove the scanner control board (SCB) cover
1. At the back of the printer, remove two screws (callout 1).
84 Chapter 1 Removal and replacement ENWW
