23. Position the control-panel cover on the control panel.
Figure 1-549 Install the cover
24. Beginning at the right side of the control-panel cover, carefully push down along the top edge of the
cover to engage the bosses.
NOTE: If the right- and left-side bosses are not fully engaged, push down along the edge of the cover
to fully seat them.
Figure 1-550 Install the control-panel cover
338 Chapter 1 Removal and replacement ENWW
