HP PageWide Enterprise Color 556

5. Position the access cover mounting feet into the slots in the top cover (callout 1), and then rotate the
cover down (callout 2) to install it.
NOTE: Press down on the cover rmly to make sure that the tabs (callout 3) snap into place.
Figure 1-84 Install the cover
3
2
1
ENWW Removal and replacement procedures 75
