HP PageWide Enterprise Color 556

Figure 1-148 Remove two screws
1
2. Release the cover by sliding it up about 10 mm (0.4 in).
NOTE: This cover can be very diicult to release. It might be easier to use a at-blade screwdriver to
pry the bottom edge of the cover up and away from the chassis.
Figure 1-149 Release the cover
ENWW Removal and replacement procedures 129
