HP PageWide Enterprise Color 556

Figure 1-152 Remove one screw
1
2. Release one tab (callout 1), and then release the cover by sliding it up about 10 mm (0.4 in).
NOTE: This cover can be very diicult to release. It might be easier to use a at-blade screwdriver to
pry the bottom edge of the cover up and away from the chassis.
Figure 1-153 Release the cover
1
ENWW Removal and replacement procedures 131
