HP PageWide Enterprise Color 556

Figure 1-182 Install the left front cover
2. Engage the cover by sliding it down about 10 mm (0.4 in).
NOTE: Make sure that the tab (callout 1) snaps into place.
Figure 1-183 Engage the cover
1
146 Chapter 1 Removal and replacement ENWW
