HP PageWide Enterprise Color 556

19. Use a at blade screwdriver to release the scanner base cover.
NOTE: Use a screwdriver with at least a 152 mm (6 in) shaft to release the cover. This cover can be
diicult to remove and might require some force to release it from the ISA.
Figure 1-315 Release the cover
20. Remover the cover.
Figure 1-316 Remove the scanner base cover
218 Chapter 1 Removal and replacement ENWW
