3. Before proceeding, take note of the tabs and hooks on the top cover.
Figure 1-473 Tabs and hooks on the top cover
4. On the left side of the printer, remove two screws (callout 1).
Figure 1-474 Remove two screws
300 Chapter 1 Removal and replacement ENWW
