7. Push up on the cover to install it.
NOTE: Installing the cover might require considerable force to snap it into place
Figure 1-533 Install the cover
8. At the left side of the printer, install two screws (callout 1).
Figure 1-534 Install two screws
330 Chapter 1 Removal and replacement ENWW
