HP PageWide Enterprise Color 556

Figure 1-747 Disconnect connectors
2
1
2. Disconnect ve connectors (callout 1), and then pass the cables and wire harness through the openings
in the formatter cage.
TIP: The cable retainer (callout 2) is easily dislodged. Do not lose the retainer.
Figure 1-748 Disconnect connectors
1
2
ENWW Removal and replacement procedures 453
