HP PageWide Enterprise Color 556

2. Disconnect four connectors (callout 1), and then pass the cables and wire harness through the openings
in the formatter cage.
Figure 1-753 Disconnect connectors
1
3. Remove three screws (callout 1).
Figure 1-754 Remove three screws
1
456 Chapter 1 Removal and replacement ENWW
