HP PageWide Enterprise Color 556

Figure 1-761 Check the locator pins
1
2
2. Install two brackets (callout 1), and then install four screws (callout 2).
NOTE: If the mounting bracket screws (callout 3) were loosened to adjust the bracket in the previous
step, tighten them now.
Figure 1-762 Install brackets and screws
2
11
3
ENWW Removal and replacement procedures 461
