2. Remove all the blue shipping tape.
IMPORTANT: The replacement PM shown is the 586. For the 556, the shipping tape has identical
placement (except for the tape on the top cover).
NOTE: The shipping tape is reusable. Use the shipping tape from the replacement print mechanism
(PM) to prepare the defective unit (DU) for shipping.
Figure 1-784 Remove the shipping tape
478 Chapter 1 Removal and replacement ENWW
