HP PageWide Enterprise Color 556

11. Remove the USB port cover.
Figure 1-899 Remove the USB port cover
12. Remove three screws (callout 1) to release the USB port PCA (callout 2), and then release the cable from
the retainers (callout 3).
Figure 1-900 Remove screws and release the cable
1
2
3
542 Chapter 1 Removal and replacement ENWW
