HP PageWide Enterprise Color 556

10. At the rear of the printer, connect two connectors (callout 1) to the SCB.
Figure 1-921 Connect two connectors
1
11. Align the tabs on the back side of the SCB cover with the slots in the printer.
Figure 1-922 Align the tabs on the SCB cover
ENWW Removal and replacement procedures 553
