HP PageWide Enterprise Color 556

14. At the front of the printer (control panel area), install two screws (callout 1).
Figure 1-925 Install two screws
1
15. Install the cable in the retainers (callout 1), position the USB on the mounting bosses (callout 2), and
then install three screws (callout 3).
Figure 1-926 Install the USB port PCA
3
2
1
ENWW Removal and replacement procedures 555
