Table 2-4 Covers (586 models)
Ref Description Part number Qty
1 Cover, rear G1W39-67919 1
2 Output bin G1W39-67944 1
3 Cover, image scanner base (586) G1W39-67937 1
4 Cover, right (outer) G1W39-67922 1
5 Flap-eject assembly G1W39-67949 1
6 Cover, top (586) G1W39-67920 1
7 Cover, front (586) G1W39-67918 1
8 Cover, left front G1W39-67916 1
9 Door, left G1W39-67926 1
10 Cover, left rear G1W39-67917 1
Not shown Cover, lower back scanner control board (586) G1W39-67936 1
Not shown Cover, formatter G1W39-67915 1
Not shown Strap, left door, front CN598-67002 1
Not shown Strap, left door, rear CN598-67003 1
Not shown Cover, ISS G1W39-67950 1
Not shown Cover, HIP G1W39-40003 1
Not shown Cover, USB G1W39-40019 1
Not shown Bezel, control panel G1W39-40002 1
Not shown Trim, control panel G1W39-40005 1
1
To access HP PartSurfer information, go to http://partsurfermobile.hp.com/.
ENWW Parts and diagrams: Covers 627
