Table 2-5 Internal assemblies
Ref Description Part number Qty
1 Multi-function print mechanism kit (586) G1W41-67901 1
2 Power supply, universal 110V and 220V G1W39-67912 1
3 Formatter PCA assembly (556) G1W46-67911 1
3 Formatter PCA assembly—China only (556) G1W46-67912 1
3 Formatter PCA assembly (586) G1W39-67914 1
3 Formatter PCA assembly—China only (586) G1W39-67939 1
4 Single-function print mechanism kit (556) G1W47-67901 1
5 Rollers, separation/pick, Tray 2 CN598-67018 1
5 Rollers, separation/pick, Tray 3 D3Q21-67002 1
5 Rollers, separation/pick, Trays 4 and 5 D3Q21-67003 1
6 Tray 2 G1W39-67955 1
7 Ink collection unit B5L04-67906 1
Not shown Tray 3 assembly and feeder kit G1W39-67952 1
Not shown Tray 3 (tray only) G1W39-67956 1
Not shown Tray 4 assembly and feeder kit G1W39-67953 1
Not shown Tray 4 (tray only) G1W39-67957 1
Not shown Tray 5 assembly and feeder kit G1W39-67954 1
Not shown Tray 5 (tray only) G1W39-67958 1
Not shown Cable, power supply kit G1W39-67913 1
Not shown 320 GB hard disk drive (HDD; 586 all; 556xh) G1W41-67902 1
Not shown embedded MultiMedia Card (eMMC; 556dn) G1W47-67902 1
Not shown Fax PCA (586f/z service kit) CC487-67901 1
Not shown Print bar restraint kit D3Q21-67004 1
Not shown Wet ship cap D3Q24-67041 1
Not shown Advanced cleaning pad kit CN459-67006 1
Not shown Ship/move kit G1W39-67948 1
1
To access HP PartSurfer information, go to http://partsurfermobile.hp.com/.
