5 - 34
IPN 074-397-P1G
HAPSITE Smart Operating Manual
6 Wait for the heaters to reach the set temperatures (see Figure 5-50).
Figure 5-50 Heater Display
7 Refer to Section 13.2.3, Loading the Wells, on page 13-10 for detailed
instructions and information on loading the sample vials into the wells.
8 Place the headspace needle in the 40 mL vial that contains the sample. Gently
depress into sample vial. See Figure 5-51.
The headspace needle is very sharp.
Figure 5-51 Headspace Needle
