5 - 39
IPN 074-397-P1G
HAPSITE Smart Operating Manual
8 Wait for temperatures to stabilize. See Figure 5-57.
Figure 5-57 HSS Heater Display
9 The sample must be heated for 20 minutes prior to sampling.
10 Place the headspace needle in the 40 mL vial that contains the sample. Gently
depress into sample vial. See Figure 5-58. Refer to Section 13.2.3, Loading the
Wells, on page 13-10.
The headspace needle is very sharp.
Figure 5-58 Loading the Wells
11 Press the Run button.
12 Wait for method to run. See Figure 5-59.
