15 - 28
IPN 074-397-P1G
HAPSITE Smart Operating Manual
3 Clean the aluminum gasket with methanol on a lint free wipe. Be careful to
handle the aluminum gasket by the outer band. Do not let the knife-edges
on the inner ring get nicked. See Figure 15-24.
Figure 15-24 Cleaning Aluminum Gasket
4 Remove the new NEG Pump from the protective container. See Figure
15-25.
The NEG Pump is stored under a vacuum in Nitrogen
environment. The shelf life is 5 years. If the vacuum is
compromised the shelf life is reduced to 1 year.
HINT: Remove the o-ring and seating ring assembly from the new NEG Pump.
