3 WLAN Mode
3.6 Modulation Analysis Measurement
Index: n Results Returned
–
9+12*(N-1)+9. -999.0(Reserved)
–
9+12*(N-1)+10. -999.0(Reserved)
–
9+12*(N-1)+11. -999.0(Reserved)
35 The results corresponding to Burst info window of Burst & Sig Info view
The results will be available except 802.11bg, otherwise it will return one value -999.0
The total number of results is 10 + Number of Burst Info Type * 5
The first 10 results are:
1.
Radio standard
Returned Value Radio Standard
1 IEEE802_11ag
2 IEEE802_11bg
3 IEEE802_DSSSOFDM
4 IEEE802_11n20M
5 IEEE802_11n40M
6 IEEE802_11ac20M
7 IEEE802_11ac40M
8 IEEE802_11ac80M
9 IEEE802_11acTwo80M
10 IEEE802_11ac160M
11 IEEE802_11ah1M
12 IEEE802_11ah2M
13 IEEE802_11ah4M
14 IEEE802_11ah8M
15 IEEE802_11ah16M
16 IEEE802_11jp10M
17 IEEE802_11P5M
18 IEEE802_11af6M
19 IEEE802_11af7M
20 IEEE802_11af8M
21 IEEE802_11ax20M
22 IEEE802_11ax40M
23 IEEE802_11ax80M
24 IEEE802_11axTwo80M
