3 WLAN Mode
3.6 Modulation Analysis Measurement
Index: n Results Returned
Returned Value Radio Standard
25 IEEE802_11ax160M
26 IEEE802_11be20M
27 IEEE802_11be40M
28 IEEE802_11be80M
29 IEEE802_11be160M
30 IEEE802_11be320M
2.
Standard Mode
Returned Value Standard Mode
0 StdModeNonHT
1 StdModeHT_MM
2 StdModeHT_GF
3 StdModeVHT
4 StdModeHE_SU
5 StdModeHE_MU
6 StdModeHE_EXT
7 StdModeHE_TRIG_BASED
8 StdModeHE_TRIG_FRAME
9 StdModeHE_SU_Sounding_NDP
10 StdModeHE_TRIG_BASED_NDP
11 StdModeEHT_MU
12 StdModeEHT_TRIG_BASED
13 StdModeEHT_Sounding_NDP
-999 StdModeUnknown
3.
Standard Format
If radio standard is either of 11a/11n/11ac/11af/11ax/11be,
Returned
Value
Standard Format Meaning
0 Std80211a A non-HT (Legacy) 20 MHz IEEE 802.11a signal was
found
1 Std80211n20GF An IEEE 802.11n HT-greenfield 20 MHz signal was
found
2 Std80211n20MM An IEEE 802.11n HT-mixed Mode 20 MHz signal was
found
