3 WLAN Mode
3.6 Modulation Analysis Measurement
Index: n Results Returned
Returned
Value
Standard Format Meaning
3 Std80211n40GF An IEEE 802.11n HT-greenfield 40 MHz signal was
found
4 Std80211n40MM An IEEE 802.11n HT-mixed Mode 40 MHz signal was
found
5 Std80211ac40DL An IEEE 802.11 40 MHz non-HT Duplicate signal was
found
6 Std80211ac20 An IEEE 802.11ac 20 MHz VHT signal was found
7 Std80211ac40 An IEEE 802.11ac 40 MHz VHT signal was found
8 Std80211ac80 An IEEE 802.11ac 80 MHz VHT signal was found
9 Std80211ac160 An IEEE 802.11ac 160 MHz VHT signal was found
10 Std80211ac80DL An IEEE 802.11 80 MHz non-HT Duplicate signal was
found
11 Std80211ac160DL An IEEE 802.11 160 MHz non-HT Duplicate signal was
found
12 Std80211ax20 An IEEE 802.11ax 20 MHz VHT signal was found
13 Std80211ax40 An IEEE 802.11ax 40 MHz VHT signal was found
14 Std80211ax80 An IEEE 802.11ax 80 MHz VHT signal was found
15 Std80211ax160 An IEEE 802.11ax 160 MHz VHT signal was found
16 Std80211be20 An IEEE 802.11be 20 MHz EHT signal was found
17 Std80211be40 An IEEE 802.11be 40 MHz EHT signal was found
18 Std80211be80 An IEEE 802.11be 80 MHz EHT signal was found
19 Std80211be160 An IEEE 802.11be 160 MHz EHT signal was found
20 Std80211be320 An IEEE 802.11be 320 MHz EHT signal was found
21 Std80211be320DL An IEEE 802.11 320 MHz non-HT Duplicate signal was
found
-999 Unknown
If radio standard is 11ah,
Returned Value Standard Format
0 StdModeShort
1 StdModeShortDup
2 StdModeLong
3 StdModeLongDup
4 StdModeS1G1Mdup
5 StdModeUnknown
4.
StreamsOut: The number of streams
