3 WLAN Mode
3.6 Modulation Analysis Measurement
Index: n Results Returned
5.
HTSigStatus
Returned Value HTSigStatus Meaning
0 HdrStatNone No Header expected
1 HdrStatUnk Unknown status
2 HdrStatNotFound Expected Header but didn’t find it
3 HdrStatErrBits Invalid bits found
4 HdrStatErrCRC Checksum failed
5 HdrStatOK
6.
LsigStatus
Returned Value LsigStatus Meaning
0 HdrStatNone No Header expected
1 HdrStatUnk Unknown status
2 HdrStatNotFound Expected Header but didn’t find it
3 HdrStatErrBits Invalid bits found
4 HdrStatErrCRC Checksum failed
5 HdrStatOK
7.
SigAStatus / U-SigStatus
If radio standard is either of 11n/11ac/11af/11ax, it’s SigAStatus
If radio standard is 11be, it’s U-SigStatus
Returned Value LsigStatus Meaning
0 HdrStatNone No Header expected
1 HdrStatUnk Unknown status
2 HdrStatNotFound Expected Header but didn’t find it
3 HdrStatErrBits Invalid bits found
4 HdrStatErrCRC Checksum failed
5 HdrStatOK
If radio standard is 11ah, -999.0
8.
SigBStatus / EHT-SigStatus
If radio standard is either of 11n/11ac/11af/11ax, it’s SigBStatus
If radio standard is 11be, it’s EHT-SigStatus
