Ricoh Pro 8300S Troubleshooting

1.SC Codes
365
Major Cause
 Cover registration sensor connector loose, damaged, or defective
 Sensor defective
 Master control board disconnected, defective
Solution
 Reconnect the connector.
 Clean the sensor.
 Replace the cover registration sensor.
 Replace the master control board
 Replace the sensor harness.
SC751-19
Error Name
Perfect Binder: Cover Horizontal Registration Sensor (S) Adjustment High Value Error
Pattern
D
Error Condition
The cover horizontal registration sensor (S) A/D input value was lower than 3.2 to 3.54V, and the A/D
input value did not go higher than 3.2 to 3.54V, even after cover registration sensor (S) D/A output value
output went higher than 3.7V.
Major Cause
 Cover horizontal registration sensor (S) connector loose, damaged, or defective
 Sensor defective
 Slave control board defective
Solution
 Reconnect the connector.
 Clean the sensor.
 Replace the cover horizontal registration sensor (S).
 Replace the slave control board.
 Replace the sensor harness.
SC751-20
Error Name
Perfect Binder: Cover Horizontal Registration Sensor (L) Adjustment High Value Error
