Ricoh Pro 8300S - PCDU Preventive Maintenance: Important Notes

5.Other Information
867
No.
Name
[B]
PCU Right Slide Rail Holder
PCDU Preventive Maintenance: Important Notes
Work carefully to avoid bending the ground plates when performing the following three tasks:
1. Removing the PCDU from the mainframe at the PCU slide rail stopper [A].
2. Removing the drum cleaning unit from the PCDU at the ground stay [A]
3. Replace the PM parts of the drum cleaning unit at the ground plate cover [A]
