Scanlab RTC6 PCIe Board - Page 973

RTC6 boards
Doc. Rev. 1.0.21 en-US
20 Appendix E: iDRIVE Scan Systems – Control Commands and Signals Transmitted to RTC Boards
973
innovators for industry
Code
HIGH
(hex)
Code
LOW
(hex)
Data type transmitted by the scan system
05 64 As of scan system firmware  5100.
Refer to “excelliSCAN Scan Heads – Functional Principle of SCANahead Servo
Control and Operation by RTC6 Boards” Manual, Chapter 3.4 ”Advanced Settings
for “Spot Distance Control””, page 25: TimeShift relative to the SCANLAB default
offset.
Notice! Generic information. May be incomplete or even incorrect for your scan system.
Always consult the dedicated scan system manual!
Module Rev.1.0.4 en-US
Code
HIGH
(hex)
Code
LOW
(hex)
Data type transmitted by the scan system
05 65 As of scan system firmware  5100.
Refer to “excelliSCAN Scan Heads – Functional Principle of SCANahead Servo
Control and Operation by RTC6 Boards” Manual, Chapter 3.4 ”Advanced Settings
for “Spot Distance Control””, page 25: TimeShift in total.
Notice! Generic information. May be incomplete or even incorrect for your scan system.
Always consult the dedicated scan system manual!
Module Rev.1.0.4 en-US
Code
HIGH
(hex)
Code
LOW
(hex)
Data type transmitted by the scan system
05 74 As of scan system firmware  51*7 + < 5090.
For High-Bandwidth Return Channel Multiplexing. For use in conjunction with
Code
HIGH
(hex) = 65
H
and Code
HIGH
(hex) = 66
H
. See corresponding Chapter incl.
example code.
16-bit
protocol
20-bit
protocol
–
Bit #0
…
Bit #15
Bit #0
…
Bit #19
–
Notice! Generic information. May be incomplete or even incorrect for your scan system.
Always consult the dedicated scan system manual!
Module Rev.1.0.4 en-US
