RTC6 boards
Doc. Rev. 1.0.21 en-US
20 Appendix E: iDRIVE Scan Systems – Control Commands and Signals Transmitted to RTC Boards
981
innovators for industry
Code
HIGH
(hex)
65 As of scan system firmware  51*7 + < 5090.
For High-Bandwidth Return Channel Multiplexing. For use in conjunction with Code
HIGH
(hex) = 66
H
and 0574
H
. See corresponding Chapter incl. example code.
Code
LOW
(hex)
0N Sets Return Channel Multiplexing block length to N+1
that is, highest Return Channel Multiplexing index = N. In other words: number of
High-Bandwidth Return Channel Multiplexing values the iDRIVE scan system has to
transmit.
Allowed values: 1; 2; 3; 4; 6; 8; 12; 16 (= integer divisor of 192  16).
8N Sets the next to-be-configured Return Channel Multiplexing index to N.
In other words: Defines the position where the signal is transmitted.
Notice! Generic information. May be incomplete or even incorrect for your scan system.
Always consult the dedicated scan system manual!
Module Rev.1.0.4 en-US
Code
HIGH
(hex)
66 As of scan system firmware  51*7 + < 5090.
For High-Bandwidth Return Channel Multiplexing. For use in conjunction with Code
HIGH
(hex) = 65
H
and 0574
H
. See corresponding Chapter incl. example code.
Code
LOW
(hex)
NN Sets the return value for the current index to NN = writes the signal value to this
index.
For NN, you can insert the same Code
LOW
values as for SetMode, see
Code
LOW
= 00
H
(XY2-100 status word), Code
LOW
= 01
H
(Actual position
(angular position of galvanometer scanners)) etc.
Notice! Generic information. May be incomplete or even incorrect for your scan system.
Always consult the dedicated scan system manual!
Module Rev.1.0.4 en-US
