Scanlab RTC6 PCIe Board - Page 980

RTC6 boards
Doc. Rev. 1.0.21 en-US
20 Appendix E: iDRIVE Scan Systems – Control Commands and Signals Transmitted to RTC Boards
980
innovators for industry
Code
HIGH
(hex)
40
As of scan system firmware  5102 +  5112.
Only excelliSCAN:
ResetTrAck
ResetTrAck causes the scan system to reset the TrAck Signal bits.
Refer to “excelliSCAN Scan Heads – Functional Principle of SCANahead Servo Control and
Operation by RTC6 Boards” Manual, Chapter 3.1.3 ”Returned Data Signal Differences: Status
Signal Behavior after Limit Value Exceedance”, page 14. For more information, for example,
about configuring the TrAck limit value, see the corresponding scan system manual.
Note: The TrAck limit value cannot be saved for subsequent new starts or resets. excelliSCAN
scan heads do not support UpdatePermanentMemory.
Code
LOW
(hex)
3A
Only excelliSCAN:
Reset TrAck Signal bits.
Notice! Generic information. May be incomplete or even incorrect for your scan system.
Always consult the dedicated scan system manual!
Module Rev.1.0.4 en-US
Code
HIGH
(hex)
50 As of scan system firmware  5100.
Only excelliSCAN:
Refer to “excelliSCAN Scan Heads – Functional Principle of SCANahead Servo Control and
Operation by RTC6 Boards” Manual, Chapter 3.4 ”Advanced Settings for “Spot Distance
Control””, page 25: dT
high
.
Notice! Generic information. May be incomplete or even incorrect for your scan system.
Always consult the dedicated scan system manual!
Module Rev.1.0.4 en-US
Code
HIGH
(hex)
51
As of scan system firmware  5100.
Only excelliSCAN:
Refer to “excelliSCAN Scan Heads – Functional Principle of SCANahead Servo Control and
Operation by RTC6 Boards” Manual, Chapter 3.4 ”Advanced Settings for “Spot Distance
Control””, page 25: dT
low
.
Notice! Generic information. May be incomplete or even incorrect for your scan system.
Always consult the dedicated scan system manual!
Module Rev.1.0.4 en-US
