Analog-to-digital converters (ADC) RM0440

702/2126 RM0440 Rev 4

21.6.8 ADC watchdog threshold register 1 (ADC_TR1)

Address offset: 0x20

Reset value: 0x0FFF 0000

Bits 31:27 Reserved, must be kept at reset value.

Bits 26:0 SMP[18:10][2:0]: Channel x sampling time selection

These bits are written by software to select the sampling time individually for each channel.

During sampling cycles, the channel selection bits must remain unchanged.

000: 2.5 ADC clock cycles

001: 6.5 ADC clock cycles

010: 12.5 ADC clock cycles

011: 24.5 ADC clock cycles

100: 47.5 ADC clock cycles

101: 92.5 ADC clock cycles

110: 247.5 ADC clock cycles

111: 640.5 ADC clock cycles

Note: The software is allowed to write these bits only when ADSTART=0 and JADSTART=0

(which ensures that no conversion is ongoing).

Some channels are not connected physically. Keep the corresponding SMPx[2:0]

setting to the reset value.

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

Res. Res. Res. Res. HT1[11:0]

rw rw rw rw rw rw rw rw rw rw rw rw

1514131211109876543210

Res. AWDFILT[2:0] LT1[11:0]

rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw

Bits 31:28 Reserved, must be kept at reset value.

Bits 27:16 HT1[11:0]: Analog watchdog 1 higher threshold

These bits are written by software to define the higher threshold for the analog watchdog 1.

Refer to Section 21.4.28: Analog window watchdog (AWD1EN, JAWD1EN, AWD1SGL, AWD1CH,

AWD2CH, AWD3CH, AWD_HTx, AWD_LTx, AWDx)

Note: The software is allowed to write these bits only when ADSTART=0 and JADSTART=0 (which

ensures that no conversion is ongoing).
