RM0440 Rev 4 703/2126

RM0440 Analog-to-digital converters (ADC)

724

21.6.9 ADC watchdog threshold register 2 (ADC_TR2)

Address offset: 0x24

Reset value: 0x00FF 0000

Bits 15: Reserved, must be kept at reset value.

Bits 14:12 AWDFILT: Analog watchdog filtering parameter

This bit is set and cleared by software.

000: No filtering

001: two consecutive detection generates an AWDx flag or an interrupt

...

111: Eight consecutive detection generates an AWDx flag or an interrupt

Note: The software is allowed to write this bit only when ADSTART=0 (which ensures that no

conversion is ongoing).

Bits 11:0 LT1[11:0]: Analog watchdog 1 lower threshold

These bits are written by software to define the lower threshold for the analog watchdog 1.

Refer to Section 21.4.28: Analog window watchdog (AWD1EN, JAWD1EN, AWD1SGL, AWD1CH,

AWD2CH, AWD3CH, AWD_HTx, AWD_LTx, AWDx)

Note: The software is allowed to write these bits only when ADSTART=0 and JADSTART=0 (which

ensures that no conversion is ongoing).

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

Res. Res. Res. Res. Res. Res. Res. Res. HT2[7:0]

rw rw rw rw rw rw rw rw

1514131211109876543210

Res. Res. Res. Res. Res. Res. Res. Res. LT2[7:0]

rw rw rw rw rw rw rw rw

Bits 31:24 Reserved, must be kept at reset value.

Bits 23:16 HT2[7:0]: Analog watchdog 2 higher threshold

These bits are written by software to define the higher threshold for the analog watchdog 2.

Refer to Section 21.4.28: Analog window watchdog (AWD1EN, JAWD1EN, AWD1SGL, AWD1CH,

AWD2CH, AWD3CH, AWD_HTx, AWD_LTx, AWDx)

Note: The software is allowed to write these bits only when ADSTART=0 and JADSTART=0 (which

ensures that no conversion is ongoing).

Bits 15:8 Reserved, must be kept at reset value.

Bits 7:0 LT2[7:0]: Analog watchdog 2 lower threshold

These bits are written by software to define the lower threshold for the analog watchdog 2.

Refer to Section 21.4.28: Analog window watchdog (AWD1EN, JAWD1EN, AWD1SGL, AWD1CH,

AWD2CH, AWD3CH, AWD_HTx, AWD_LTx, AWDx)

Note: The software is allowed to write these bits only when ADSTART=0 and JADSTART=0 (which

ensures that no conversion is ongoing).
