Digital-to-analog converter (DAC) RM0440
764/2126 RM0440 Rev 4
22.7.15 DAC calibration control register (DAC_CCR)
Address offset: 0x38
Reset value: 0x00XX 00XX
Bits 26:16 Reserved, must be kept at reset value.
Bit 15 BWST1: DAC channel1 busy writing sample time flag
This bit is systematically set just after Sample and hold mode enable and is set each time the
software writes the register DAC_SHSR1, It is cleared by hardware when the write operation of
DAC_SHSR1 is complete. (It takes about 3 LSI/LSE periods of synchronization).
0:There is no write operation of DAC_SHSR1 ongoing: DAC_SHSR1 can be written
1:There is a write operation of DAC_SHSR1 ongoing: DAC_SHSR1 cannot be written
Bit 14 CAL_FLAG1: DAC channel1 calibration offset status
This bit is set and cleared by hardware
0: calibration trimming value is lower than the offset correction value
1: calibration trimming value is equal or greater than the offset correction value
Bit 13 DMAUDR1: DAC channel1 DMA underrun flag
This bit is set by hardware and cleared by software (by writing it to 1).
0: No DMA underrun error condition occurred for DAC channel1
1: DMA underrun error condition occurred for DAC channel1 (the currently selected trigger is
driving DAC channel1 conversion at a frequency higher than the DMA service capability rate)
Bit 12 DORSTAT1: DAC channel1 output register status bit
This bit is set and cleared by hardware. It is applicable only when the DAC operates in
Double data mode.
0: DOR[11:0] is used actual DAC output
1: DORB[11:0] is used actual DAC output
Bit 11 DAC1RDY: DAC channel1 ready status bit
This bit is set and cleared by hardware.
0: DAC channel1 is not yet ready to accept the trigger nor output data
1: DAC channel1 is ready to accept the trigger or output data
Bits 10:0 Reserved, must be kept at reset value.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. OTRIM2[4:0]
rw rw rw rw rw
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. OTRIM1[4:0]
rw rw rw rw rw
Bits 31:21 Reserved, must be kept at reset value.
Bits 20:16 OTRIM2[4:0]: DAC channel2 offset trimming value
These bits are available only on dual-channel DACs. Refer to Section 22.3: DAC
implementation.
Bits 15:5 Reserved, must be kept at reset value.
Bits 4:0 OTRIM1[4:0]: DAC channel1 offset trimming value
