High-resolution timer (HRTIM) RM0440
998/2126 RM0440 Rev 4
27.5.30 HRTIM timer x output 2 reset register (HRTIM_RSTx2R) (x = A to F)
Address offset: Block A: 0x0C8
Address offset: Block B: 0x148
Address offset: Block C: 0x1C8
Address offset: Block D: 0x248
Address offset: Block E: 0x2C8
Address offset: Block F: 0x348
Reset value: 0x0000 0000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
UPDAT
E
EXT
EVNT1
0
EXT
EVNT9
EXT
EVNT8
EXT
EVNT7
EXT
EVNT6
EXT
EVNT5
EXT
EVNT4
EXT
EVNT3
EXT
EVNT2
EXT
EVNT1
TIM
EVNT9
TIM
EVNT8
TIM
EVNT7
TIM
EVNT6
TIM
EVNT5
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
1514131211109876543210
TIM
EVNT4
TIM
EVNT3
TIM
EVNT2
TIM
EVNT1
MST
CMP4
MST
CMP3
MST
CMP2
MST
CMP1
MST
PER
CMP4 CMP3 CMP2 CMP1 PER
RESYN
C
SRT
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:0 Refer to HRTIM_SETx1R bits description.
These bits are defining the source which forces the Tx2 output to its inactive state.
