Fuji Xerox DocuCentre SC2020 Service Manual

05/2014
6-32
DC SC2020
6.3.3 NVM DADF
Version 1.1
General
711-024 DADF Lead Reg. Adjustment (Side 2) (82.5 mm/s) 105-135 120 0.1 mm 1) Default Value: 0 mm
(When 711-141 value is Default and 711-024 value is 120)
2) Adjustment Range (when 711-141 value is Default)
: +1.5 mm (105 pulse) / -1.5 mm (135 pulse)
3) Adjustment Range (when 711-141 value is 80 to 230)
: +5.5 mm (80 pulse) / -12.5 mm (230 pulse)
711-041 DADF Tail Edge Adjustment (Side 1) (220.0 mm/s) 0-255 151 0.0718 mm Default Value: 0 mm (151 pulse), +10.8 mm (-151 pulse) / -7.5 mm (+104 pulse)
Tail Edge adjustment = Lead Regi adjustment value + Tail Edge fine adjustment value
711-042 DADF Tail Edge Adjustment (Side 1) (165.0 mm/s) 0-255 151 0.0718 mm Default Value: 0 mm (151 pulse), +10.8 mm (-151 pulse) / -7.5 mm (+104 pulse)
Tail Edge adjustment = Lead Regi adjustment value + Tail Edge fine adjustment value
711-043 DADF Tail Edge Adjustment (Side 1) (110.0 mm/s) 0-255 151 0.0718 mm Default Value: 0 mm (151 pulse), +10.8 mm (-151 pulse) / -7.5 mm (+104 pulse)
Tail Edge adjustment = Lead Regi adjustment value + Tail Edge fine adjustment value
711-044 DADF Tail Edge Adjustment (Side 1) (82.5 mm/s) 0-255 151 0.0718 mm Default Value: 0 mm (151 pulse), +10.8 mm (-151 pulse) / -7.5 mm (+104 pulse)
Tail Edge adjustment = Lead Regi adjustment value + Tail Edge fine adjustment value
711-061 DADF Tail Edge Adjustment (Side 2) (220.0 mm/s) 0-255 151 0.0718 mm Default Value: 0 mm (151 pulse), +10.8 mm (-151 pulse) / -7.5 mm (+104 pulse)
Tail Edge adjustment = Lead Regi adjustment value + Tail Edge fine adjustment value
711-062 DADF Tail Edge Adjustment (Side 2) (165.0 mm/s) 0-255 151 0.0718 mm Default Value: 0 mm (151 pulse), +10.8 mm (-151 pulse) / -7.5 mm (+104 pulse)
Tail Edge adjustment = Lead Regi adjustment value + Tail Edge fine adjustment value
711-063 DADF Tail Edge Adjustment (Side 2) (110.0 mm/s) 0-255 151 0.0718 mm Default Value: 0 mm (151 pulse), +10.8 mm (-151 pulse) / -7.5 mm (+104 pulse)
Tail Edge adjustment = Lead Regi adjustment value + Tail Edge fine adjustment value
711-064 DADF Tail Edge Adjustment (Side 2) (82.5 mm/s) 0-255 151 0.0718 mm Default Value: 0 mm (151 pulse), +10.8 mm (-151 pulse) / -7.5 mm (+104 pulse)
Tail Edge adjustment = Lead Regi adjustment value + Tail Edge fine adjustment value
711-081 Vertical Reduce/Enlarge Fine Adjustment 1
(High: TBD, Mid: 220.0 mm/s, Low: TBD)
0-40 20 0.001 Default Value: 0% (20), +/-2% (+/-20), 0.1% increments
Adjusts only the Top Speed for Feed Motor.
711-082 Vertical Reduce/Enlarge Fine Adjustment 2
(High: TBD, Mid: 165.0 mm/s, Low: TBD)
0-40 20 0.001 Default Value: 0% (20), +/-2% (+/-20), 0.1% increments
Adjusts only the Top Speed for Feed Motor.
711-083 Vertical Reduce/Enlarge Fine Adjustment 3
(High: TBD, Mid: 110.0 mm/s, Low: TBD)
0-40 20 0.001 Default Value: 0% (20), +/-2% (+/-20), 0.1% increments
Adjusts only the Top Speed for Feed Motor.
711-084 Vertical Reduce/Enlarge Fine Adjustment 4
(High: TBD, Mid: 82.5 mm/s, Low: TBD)
0-40 20 0.001 Default Value: 0% (20), +/-2% (+/-20), 0.1% increments
Adjusts only the Top Speed for Feed Motor.
711-140 DADF Lead Regi Offset NVM (Side 1) 80-230 120 0.1 mm Default Value: 0 mm (120 pulse), +4.0 mm (80 pulse) / -11.0 mm (230 pulse)
711-141 DADF Lead Regi Offset NVM (Side 2) 80-230 120 0.1 mm Default Value: 0 mm (120 pulse), +4.0 mm (80 pulse) / -11.0 mm (230 pulse)
711-142 DADF Tail Edge Replace All NVM (Side 1) 0-255 151 0.0718 mm
(x2 for Soft)
Default Value: 0 mm (151 pulse), +10.8 mm (-151 pulse) / -7.5 mm (+104 pulse)
Rewrites all data of 711-041 to 711-044 with the specified data.
711-143 DADF Tail Edge Replace All NVM (Side 2) 0-255 151 0.0718 mm
(x2 for Soft)
Default Value: 0 mm (151 pulse), +10.8 mm (-151 pulse) / -7.5 mm (+104 pulse)
Rewrites all data of 711-061 to 711-064 with the specified data.
711-144 Vertical Ratio Fine Adjustment - Replace All 0-40 20 0.001 Default Value: 0% (20), +/-2% (+/-20), 0.1% increments
Adjusts only the Top Speed for Feed Motor.
Rewrites all data of 711-081 to 711-084 with the specified data.
711-150 Loop Amount Adjustment (Side 1) (x1 Pulse) 0-9 6 40 Pulse Feed Roll Step: 0.026112
NVM 1Count: 0.026112 * 40 = 1.044 mm
711-151 Loop Amount Adjustment (Side 2) (x6 Pulse) 0-14 5 30 Pulse Exit Roll Step: 0.035904
NVM 1Count: 0.035904 * 30 = 1.077 mm
Table 1 NVM DADF
Chain-Link NVM Name
Setting
Range
Default
Value step Description
