05/2014
6-33
DC SC2020
General
6.3.3 NVM DADF
Version 1.1
711-155 Feed Gear Initialize Operation 0-1 0 - 0: Do not perform initialize operation
1: Perform initialize operation
711-158 Stop Position Adjustment During Invert (T27) 0-40 20 0.2 mm Sets the adjustment time so that the distance (step distance) is the same for every speed.
Adjustment Value (ms) = (NVM Input Value - NVM Default Value) / Transport Speed x 1000 x 0.2
(mm step).
711-159 TA Clutch OFF Timing (T21) 0-20 0 0.2 mm Sets the adjustment time so that the distance (step distance) is the same for every speed.
Adjustment Value (ms) = (NVM Input Value - NVM Default Value) / Transport Speed x 1000 x 0.2
(mm step).
711-160 Feed Clutch OFF Timing
(Side 1 Loop Unravel Timing) (T20)
0-40 20 0.2 mm Sets the adjustment time so that the distance (step distance) is the same for every speed.
Adjustment Value (ms) = (NVM Input Value - NVM Default Value) / Transport Speed x 1000 x 0.2
(mm step).
711-161 Solenoid ON Timing
(Side 2 Loop Unravel Timing) (T22)
0-40 20 0.2 mm Sets the adjustment time so that the distance (step distance) is the same for every speed.
Adjustment Value (ms) = (NVM Input Value - NVM Default Value) / Transport Speed x 1000 x 0.2
(mm step).
711-164 Document Slow Scan Size Correction Value 0-100 50 0.1 mm Correction value for [Size Detection Auto-Correction Function]
Document Size Correction Value: +/-5 mm
711-174 Nudger Lift Up Adjustment (High) (T26 ms) 0-40 20 4ms Default value: 0 ms +/-80 ms, 4 ms increments
711-175 Nudger Lift Up Adjustment (Middle) (T26 ms) 0-40 20 4ms Default value: 0 ms +/-80 ms, 4 ms increments
711-176 Nudger Lift Up Adjustment (Low) (T26 ms) 0-40 20 4ms Default value: 0 ms +/-80 ms, 4 ms increments
711-187 Letter Mode Setting 0-15 0 - Operation setting for letter documents
711-188 Prohibited Combination Jam Detection Settings (No
Mixed Mode)
0-1 1 - When in No Mixed Mode:
0: Do not detect Jams due to prohibited combinations
1: Detect Jams due to prohibited combinations
711-190 Too Long Jam Settings Switch 0-165 40 15 mm Default value: 1275 mm (40), -600 mm/+1875 mm, 15 mm increments
711-191 Too Short Jam Detection Settings 0-1 1 - 0: Do not detect Jams
1: Detect Jams
711-198 DADF OPEN SENSOR Availability 0-1 0 There is a DADF OPEN SENSOR at the DADF: 0 (DC S2010/S1810)
There is no DADF OPEN SENSOR at the DADF: 1
711-199 Drive Type 0-3 1 - 0: High, 1: Middle, 2: Low, 3: Dummy
711-202 Speed Up Start Position Adjustment During Duplex
(T25)
0-40 20 0.2 mm Sets the adjustment time so that the distance (step distance) is the same for every speed.
Adjustment Value (ms) = (NVM Input Value - NVM Default Value) / Transport Speed x 1000 x 0.2
(mm step).
711-204 Solenoid ON Timing During Invert Output (T24) 0-20 10 0.2 mm Sets the adjustment time so that the distance (step distance) is the same for every speed.
Adjustment Value (ms) = (NVM Input Value - NVM Default Value) / Transport Speed x 1000 x 0.2
(mm step).
711-205 Feed Motor Reverse Start Time Adjustment Value at
Side 2 (T1 ms)
0-20 4 4 ms Default Value: 0 ms, +80 ms/-20 ms, 4 ms increments
711-209 Invert Start Time Adjustment Value (T6 ms) 0-25 5 4 ms Default Value: 0 ms, +80 ms/-20 ms, 4 ms increments
711-213 DADF Stamp Solenoid ON Time Adjustment 0-20 5 2 ms Default value: 10 ms, +30 ms/-4 ms, 2 ms increments
711-214 DADF Stamp Position Adjustment Side 1 (T23) 0-30 15 0.5 mm Default Value: 0 mm, +7.5 mm/-7.5 mm, approx. 0.5 mm increments
Default Value is 10 mm from Tail Edge
Table 1 NVM DADF
Chain-Link NVM Name
Setting
Range
Default
Value step Description
To Next Page
