Fuji Xerox DocuCentre SC2020 Service Manual

05/2014
6-34
DC SC2020
6.3.3 NVM DADF
Version 1.1
General
711-215 DADF Stamp Position Adjustment Side 2 (T28) 0-40 20 0.2 mm Sets the adjustment time so that the distance (step distance) is the same for every speed.
Adjustment Value (ms) = (NVM Input Value - NVM Default Value) / Transport Speed x 1000 x 0.2
(mm step).
711-220 Usage of DPM Control Parameter Instructed from the
Controller
0-1 1 - 0: Cont DPM Parameter Reject
1: Cont DPM Parameter Accept
711-221 DADF DPM Control Parameter 0-255 101 - 100th Digit: Drive Type (0: High, 1: Middle, 2: Low)
10th Digit: Loop Control
1st Digit: Pre Regist Speed
711-262 DOF Adjustment 0-10 5 - Change the emphasis level of image processing.If 5 is considered as the mid level, as the number
becomes bigger (approaching 10), the emphasis level will become high. As the number becomes
smaller (approaching 0), the emphasis level will become low.
711-272 Side 1 Side Regi Adjustment Value
(ADF-IIT Combine Adjustment Value Data 3)
0-240 120 - Side 1 Side Regi Adjustment Value
711-274 Side 2 Side Regi Adjustment Value
(ADF-IIT Combine Adjustment Value Data 5)
0-240 120 - Side 2 Side Regi Adjustment Value
711-276 ADF-IIT Combine Adjustment Value Data 7 0-255 0 - Adjustment Value Data 7 sent to IIT during ADF-IIT Combine
711-277 ADF-IIT Combine Adjustment Value Data 8 0-255 0 - Adjustment Value Data 8 sent to IIT during ADF-IIT Combine
711-278 ADF-IIT Combine Adjustment Value Data 9 0-255 0 - Adjustment Value Data 9 sent to IIT during ADF-IIT Combine
711-279 ADF-IIT Combine Adjustment Value Data 10 0-255 0 - Adjustment Value Data 10 sent to IIT during ADF-IIT Combine
711-280 ADF-IIT Combine Adjustment Value Data 11 0-255 0 - Adjustment Value Data 11 sent to IIT during ADF-IIT Combine
711-281 ADF-IIT Combine Adjustment Value Data 12 0-255 0 - Adjustment Value Data 12 sent to IIT during ADF-IIT Combine
711-282 ADF-IIT Combine Adjustment Value Data 13 0-255 0 - Adjustment Value Data 13 sent to IIT during ADF-IIT Combine
711-283 ADF-IIT Combine Adjustment Value Data 14 0-255 0 - Adjustment Value Data 14 sent to IIT during ADF-IIT Combine
711-284 ADF-IIT Combine Adjustment Value Data 15 0-255 0 - Adjustment Value Data 15 sent to IIT during ADF-IIT Combine
711-297 Communication Fail Bypass 0-1 0 - 0: Communication Fail Bypass OFF
1: Communication Fail Bypass ON
Table 1 NVM DADF
Chain-Link NVM Name
Setting
Range
Default
Value step Description
