General
715-095 WREF_ADJ__BWX 70 255 140 O BW-X W-Ref correction coefficient, "Factory Settings"
715-096 WREF_ADJ__BWY 70 255 140 O BW-Y W-Ref correction coefficient, "Factory Settings"
715-097 CVT_Density_Level_ADJ_R 1 255 100 O CVT Scan Density correction coefficient Red (Use 1/100: 100= x1)
715-098 CVT_Density_Level_ADJ_G 1 255 100 O CVT Scan Density correction coefficient Green (Use 1/100)
715-099 CVT_Density_Level_ADJ_B 1 255 100 O CVT Scan Density correction coefficient Green (Use 1/100)
715-100 CVT_Density_Level_ADJ_K 1 255 100 O CVT Scan Density correction coefficient Green (Use 1/100)
715-101 Density_Level_ADJ_RGBK 80 120 100 O Highlight Fine Adjustment (Use 1/100, common for RGBK)
715-102 WREF_Offset_R 0 127 63 O Red W-Ref correction coefficient for each individual paper type.
715-103 WREF_Offset_G 0 127 63 O Green W-Ref correction coefficient for each individual paper type.
715-104 WREF_Offset_B 0 127 63 O Blue W-Ref correction coefficient for each individual paper type.
715-105 WREF_Offset_K 0 127 63 O BW W-Ref correction coefficient for each individual paper type.
715-106 IIT Paper Code 080O0: Use NVM Individual Paper Coefficient
1: J paper 2: P paper 3: C2 paper
4: Green100 paper 5: Digital Color Xpression
6: Color Tech+ 7: Xerox4200 paper
8: Xerox Business
715-110 CVT FS Side 1 Standard Adjustment 0 240 120 O Fast Scan Regi Reference Adjustment Value (0.1 mm/step) during CVT Side 1
"Factory Settings"
At Power ON, this will be overwritten by the DADF NVM (711-272) value.
715-111 CVT FS Side 2 Standard Adjustment 0 240 120 O Fast Scan Regi Reference Adjustment Value (0.1 mm/step) during CVT Side 2
"Factory Settings"
At Power ON, this will be overwritten by the DADF NVM (711-274) value.
715-112 CVT FS Side 3 Standard Adjustment 0 240 120 O Fast Scan Regi Reference Adjustment Value (0.1 mm/step) during CVT Side 3
"Factory Settings"
At Power ON, this will be overwritten by the DADF NVM (711-274) value.
715-113 CVT FS Side 4 Standard Adjustment 0 240 120 O Fast Scan Regi Reference Adjustment Value (0.1 mm/step) during CVT Side 4
"Factory Settings"
At Power ON, this will be overwritten by the DADF NVM (711-274) value.
715-158 DOF correction level DADF 0 10 5 O
715-159 DOF correction level PLT 0 10 5 O
715-165 600dpi centroidal correction level 0 10 5 O
715-166 400dpi centrioidal correction level 0 10 5 O
715-280 HOSEI_SCAN 063Ob* correction coefficient no., "Factory Settings"
715-281 LED_HOSEI_SCAN 0 19 5 O LED correction coefficient no., "Factory Settings"
Used for parameter selection at ENL
715-282 CCD Calib Y Scan Red 0 1023 O Red when scanning CCD Calib Y Patch (Reflective Ratio LSB)
"Factory Settings"
715-283 CCD Calib Y Scan Green 0 1023 0 O Red when scanning CCD Calib Y Patch (Reflective Ratio LSB)
"Factory Settings"
Table 1 NVM IIT
Chain-Link NVM Name
Setting
Range
(Minimum
Value)
Setting
Range
(Maximum
Value)
Default
Value Read/Write Description
