05/2014
6-37
DC SC2020
General
6.3.4 NVM IIT
Version 1.1
715-284 CCD Calib Y Scan Blue 0 1023 0 O Red when scanning CCD Calib Y Patch (Reflective Ratio LSB)
"Factory Settings"
715-285 CCD Calib M Scan Red 0 1023 0 O Red when scanning CCD Calib Y Patch (Reflective Ratio LSB)
"Factory Settings"
715-286 CCD Calib M Scan Green 0 1023 0 O Red when scanning CCD Calib Y Patch (Reflective Ratio LSB)
"Factory Settings"
715-287 CCD Calib M Scan Blue 0 1023 0 O Red when scanning CCD Calib Y Patch (Reflective Ratio LSB)
"Factory Settings"
715-288 CCD Calib C Scan Red 0 1023 0 O Red when scanning CCD Calib Y Patch (Reflective Ratio LSB)
"Factory Settings"
715-289 CCD Calib C Scan Green 0 1023 0 O Red when scanning CCD Calib Y Patch (Reflective Ratio LSB)
"Factory Settings"
715-290 CCD Calib C Scan Blue 0 1023 0 O Red when scanning CCD Calib Y Patch (Reflective Ratio LSB)
"Factory Settings"
715-291 CCD Calib PK Scan Red 0 1023 0 O Red when scanning CCD Calib Y Patch (Reflective Ratio LSB)
"Factory Settings"
715-292 CCD Calib PK Scan Green 0 1023 0 O Red when scanning CCD Calib Y Patch (Reflective Ratio LSB)
"Factory Settings"
715-293 CCD Calib PK Scan Blue 0 1023 0 O Red when scanning CCD Calib Y Patch (Reflective Ratio LSB)
"Factory Settings"
715-300 A6 / Postcard Detection 020O0: The default in the Table
1: A6 SEF
2: Japanese Postcard SEF (mm series) or Postcard SEF (inch series)
715-302 A4S/8.5in Detection 2 063O0: 210 mm 1: 211 mm 2: 212 mm 3: 213 mm
4: 214 mm 5: 215 mm 6: 216 mm
715-303 B5/8x10 Detection 030O0: The default in the Table
1: Detect as B5 LEF or Executive LEF
2: Detect as 8x10 LEF/8x10.5 LEF Mixed
3: For design verification, performance not guaranteed
715-305 8.5x13/8.5x14 Detection 030O0: The default in the Table
1: For design verification, performance not guaranteed
2: 13 inch
3: 14 inch
715-306 Original detection table for special paper 020O0: Special documents not supported
1: A4 LEF when APS is OFF and A3 when APS in ON
2: Letter LEF when APS is OFF and 17 inch when APS in ON
715-307 Change Size Table 152O1: Inch 13-2
2: mm-2
3: mm
4: Inch 13-1
5: Inch 14
Table 1 NVM IIT
Chain-Link NVM Name
Setting
Range
(Minimum
Value)
Setting
Range
(Maximum
Value)
Default
Value Read/Write Description
To Next Page
