05/2014
6-38
DC SC2020
6.3.4 NVM IIT
Version 1.1
General
715-310 A3/11x17 Detection 030O0: The default in the Table
1: A3 SEF
2: For design verification, performance not guaranteed
3: Detect as A3 SEF/11x17 SEF Mixed
715-311 A4/8.5x11 Detection 030O0: The default in the Table
1: A4 LEF
2: For design verification, performance not guaranteed
3: Detect as 8.5x11 LEF/A4 LEF Mixed
715-312 A6 SEF Threshold 50 110 90 O Changes the Fast Scan direction threshold value for Non-standard, as well as Japa-
nese Postcard SEF, Postcard SEF, and A6 SEF. When other than 50 to 110 has been
set, the Fast Scan direction threshold value is 90 mm.
50: 50 mm
[Down] (1 mm increment/step)
110: 110 mm
715-317 No. of AOC Fail 0 65535 0 O
715-344 Document Size Detection 030O(IISS)
0: Detection by 4 registers
1: Detection by 3 registers (countermeasure for dirt)
(IPoC)
0: Detection by 4 registers
1: Detection by 3 registers (countermeasure for dirt); 2 at open + the document edge at
close
2: Detection by 3 registers (countermeasure for dirt); 2 at open + the ladder edge at
close
3: Detection by 2 registers (countermeasure for dirt); 2 at open
715-345 GCO/TFX Size Detection 011O0: GCO (16K/8K = 270x195/270x390)
1: TFX (16K/8K = 267x194/267x388)
715-346 B4/8-Kai Detection 063O0: 256 mm 1: 258 mm 2: 260 mm 3: 262 mm
4: 264 mm 5: 266 mm 6: 268 mm
715-347 8-Kai/11x17 Detection 063O0: 269 mm 1: 271 mm 2: 273 mm 3: 275 mm
4: 277 mm 5: 279 mm 6: 281 mm
715-349 B6/5x7 Detection 020O0: The default in the Table
1: B6 SEF
2: 5x7 SEF
715-418 AOCerr 0 255 0 O No. of times the AOC flow has ended abnormally
Table 1 NVM IIT
Chain-Link NVM Name
Setting
Range
(Minimum
Value)
Setting
Range
(Maximum
Value)
Default
Value Read/Write Description
To Next Page
