05/2014
6-66
DC SC2020
6.3.10 NVM 749_LPH List
Version 1.1
General
749-057 LPH_VREFLPH_THERM_A_RESULT_Y 0 0 255 Stores the IBY Register THERM_A_RESULT value when setting the light amount (when
Procon light amount is requested).
-O O
749-058 LPH_VREFLPH_THERM_A_RESULT_
M
0 0 255 Stores the IBY Register THERM_A_RESULT value when setting the light amount (when
Procon light amount is requested).
-O O
749-059 LPH_VREFLPH_THERM_A_RESULT_C 0 0 255 Stores the IBY Register THERM_A_RESULT value when setting the light amount (when
Procon light amount is requested).
-O O
749-060 LPH_VREFLPH_THERM_A_RESULT_K 0 0 255 Stores the IBY Register THERM_A_RESULT value when setting the light amount (when
Procon light amount is requested).
-O O
749-061 LPH_VREFLPH_THERM_B_RESULT_Y 0 0 255 Stores the IBY Register THERM_B_RESULT value when setting the light amount (when
Procon light amount is requested).
-O O
749-062 LPH_VREFLPH_THERM_B_RESULT_
M
0 0 255 Stores the IBY Register THERM_B_RESULT value when setting the light amount (when
Procon light amount is requested).
-O O
749-063 LPH_VREFLPH_THERM_B_RESULT_C 0 0 255 Stores the IBY Register THERM_B_RESULT value when setting the light amount (when
Procon light amount is requested).
-O O
749-064 LPH_VREFLPH_THERM_B_RESULT_K 0 0 255 Stores the IBY Register THERM_B_RESULT value when setting the light amount (when
Procon light amount is requested).
-O O
749-065 LPH_OUT_Y 1023 0 2047 Light amount of Procon demand (Refer to Procon specification) - O O
749-066 LPH_OUT_M 1023 0 2047 Light amount of Procon demand (Refer to Procon specification) - O O
749-067 LPH_OUT_C 1023 0 2047 Light amount of Procon demand (Refer to Procon specification) - O O
749-068 LPH_OUT_K 1023 0 2047 Light amount of Procon demand (Refer to Procon specification) - O O
749-069 LPH_VREFLPH_THERM_REF 40 0 255 Reference Value to derivate the light amount difference from temperature (unit degrees) - O O
749-070 LPH_VREFLPH_THERM_K 25 0 255 Temperature difference contribution (use with /1000) to derivate the light amount differ-
ence from temperature
Example: 25 => 0.025%
-O O
749-071 LPH_OUT_LOCAL_Y 1024 0 2047 Value to be set in VREF_LPH which was calculated from LPH_OUT - O O
749-072 LPH_OUT_LOCAL_M 1024 0 2047 Value to be set in VREF_LPH which was calculated from LPH_OUT - O O
749-073 LPH_OUT_LOCAL_C 1024 0 2047 Value to be set in VREF_LPH which was calculated from LPH_OUT - O O
749-074 LPH_OUT_LOCAL_K 1024 0 2047 Value to be set in VREF_LPH which was calculated from LPH_OUT - O O
749-076 LPH_STY_I_ON_A 245 0 65535 Static for coefficient that derivate the value that specifies the reset signal timing from
lighting time, IOT operation. (Use with /10000)
Default Value: 245 => 0.0245
-O O
749-077 LPH_STY_I_ON_B 13 0 255 Static for coefficient that derivate the value that specifies the reset signal timing from
lighting time, IOT operation.
-O O
749-078 LPH_STY_I_ON_C 63 0 255 Value that specifies the reset signal timing from lighting time that exceeded the specified
amount of time.
-O O
749-079 LPH_STY_I_ON_D 2047 0 2047 Use LPH_OUT_LOCAL to derivate the Light Amount Setting Register. Threshold Value
to compare to LPH_OUT_LOCAL.
-O O
749-080 LPH_MAX_PLS_A 319 0 65535 Static for coefficient that derivate the maximum no. of light pulse, IOT operation. (Use
with /10000)
Default Value: 329 => 0.0329
-O O
749-081 LPH_MAX_PLS_B 9 0 255 Static for coefficient that derivate the maximum no. of light pulse, IOT operation. - O O
Table 1 NVM 749_LPH List
Chain-Link NVM Name
Default
Value
Minimum
value
Maximum
value Description Unit
Write
Allowed/
Protected
Can be
initialized
To Next Page
