05/2014
6-67
DC SC2020
General
6.3.10 NVM 749_LPH List
Version 1.1
749-082 LPH_MAX_PLS_C 0 0 255 Maximum No. of Light Pulse when lighting time exceeds the specified amount of time - O O
749-083 LPH_MAX_PLS_D 2047 0 2047 Use LPH_OUT_LOCAL to derivate the Light Amount Setting Register. Threshold Value
to compare to LPH_OUT_LOCAL.
-O O
749-084 LPH_MIN_PLS_A 171 0 65535 Static for coefficient that derivate the minimum no. of light pulse, IOT operation. (Use
with /10000)
Default Value: 158 => 0.0158
-O O
749-085 LPH_MIN_PLS_B -3 -127 127 Static for coefficient that derivate the minimum no. of light pulse, IOT operation. - O O
749-086 LPH_MIN_PLS_C 2 0 255 Minimum No. of Light Pulse when lighting time is under the specified amount of time - O O
749-087 LPH_MIN_PLS_D 352 0 2047 Use LPH_OUT_LOCAL to derivate the Light Amount Setting Register. Threshold Value
to compare to LPH_OUT_LOCAL.
-O O
749-088 LPH_LIGHT_ON 255 0 255 Perform Determination Switch for LPH Light Setting.
When the following each bit is 0, write "0" to the supported IBY register.
0bit: Y Color SERIAL_SLED_ON Setting
1bit: Y Color WIDTH Setting
2bit: M Color SERIAL_SLED_ON Setting
3bit: M Color WIDTH Setting
4bit: C Color SERIAL_SLED_ON Setting
5bit: C Setting WIDTH Setting
6bit: K Color SERIAL_SLED_ON Setting
7bit: K Color WIDTH Setting
-O O
749-089 LPH_PIXCEL_SUM_Y 0 0 4294967295 Store the IBY Pixel Count Register Lead Value to NVM.
· bit0~7: IBY Register Pixel Count Result Output (0~7bit)
· bit8~15: IBY Register Pixel Count Result Output (8~15bit)
· bit16~23: IBY Register Pixel Count Result Output (16~23bit)
· bit24~31: Pixel Count Result Output (24~31bit)
-O O
749-090 LPH_PIXCEL_SUM_M 0 0 4294967295 Store the IBY Pixel Count Register Lead Value to NVM.
· bit0~7: IBY Register Pixel Count Result Output (0~7bit)
· bit8~15: IBY Register Pixel Count Result Output (8~15bit)
· bit16~23: IBY Register Pixel Count Result Output (16~23bit)
· bit24~31: Pixel Count Result Output (24~31bit)
-O O
749-091 LPH_PIXCEL_SUM_C 0 0 4294967295 Store the IBY Pixel Count Register Lead Value to NVM.
· bit0~7: IBY Register Pixel Count Result Output (0~7bit)
· bit8~15: IBY Register Pixel Count Result Output (8~15bit)
· bit16~23: IBY Register Pixel Count Result Output (16~23bit)
· bit24~31: Pixel Count Result Output (24~31bit)
-O O
749-092 LPH_PIXCEL_SUM_K 0 0 4294967295 Store the IBY Pixel Count Register Lead Value to NVM.
· bit0~7: IBY Register Pixel Count Result Output (0~7bit)
· bit8~15: IBY Register Pixel Count Result Output (8~15bit)
· bit16~23: IBY Register Pixel Count Result Output (16~23bit)
· bit24~31: Pixel Count Result Output (24~31bit)
-O O
749-093 LPH_LIFE_Y 0 0 4294967295 Save the LPH_PIXCEL_SUM accumulated value, Total no. of LPH light dot.
(6 bytes is needed for NVM restriction, but lower 2 bytes shall be round off. )
-O X
Table 1 NVM 749_LPH List
Chain-Link NVM Name
Default
Value
Minimum
value
Maximum
value Description Unit
Write
Allowed/
Protected
Can be
initialized
To Next Page
