6.3.10 NVM 749_LPH List
Version 1.1
General
749-094 LPH_LIFE_M 0 0 4294967295 Save the LPH_PIXCEL_SUM accumulated value, Total no. of LPH light dot.
(6 bytes is needed for NVM restriction, but lower 2 bytes shall be round off. )
-O X
749-095 LPH_LIFE_C 0 0 4294967295 Save the LPH_PIXCEL_SUM accumulated value, Total no. of LPH light dot.
(6 bytes is needed for NVM restriction, but lower 2 bytes shall be round off. )
-O X
749-096 LPH_LIFE_K 0 0 4294967295 Save the LPH_PIXCEL_SUM accumulated value, Total no. of LPH light dot.
(6 bytes is needed for NVM restriction, but lower 2 bytes shall be round off. )
-O X
749-097 LPH_THERM_A_RESULT_Y 0 0 255 Store the IBY Register THERM_A_RESULT Value. - O O
749-098 LPH_THERM_A_RESULT_M 0 0 255 Store the IBY Register THERM_A_RESULT Value. - O O
749-099 LPH_THERM_A_RESULT_C 0 0 255 Store the IBY Register THERM_A_RESULT Value. - O O
749-100 LPH_THERM_A_RESULT_K 0 0 255 Store the IBY Register THERM_A_RESULT Value. - O O
749-101 LPH_THERM_B_RESULT_Y 0 0 255 Store the IBY Register THERM_B_RESULT Value. - O O
749-102 LPH_THERM_B_RESULT_M 0 0 255 Store the IBY Register THERM_B_RESULT Value. - O O
749-103 LPH_THERM_B_RESULT_C 0 0 255 Store the IBY Register THERM_B_RESULT Value. - O O
749-104 LPH_THERM_B_RESULT_K 0 0 255 Store the IBY Register THERM_B_RESULT Value. - O O
749-105 LPH_TP5_CHIP_ENB_A_Y 255 0 255 Specify turning the light ON/OFF in 0~7Chip Forcible Lighting Mode. For Erase Pattern - O O
749-106 LPH_TP5_CHIP_ENB_A_M 255 0 255 Specify turning the light ON/OFF in 0~7Chip Forcible Lighting Mode. For Erase Pattern - O O
749-107 LPH_TP5_CHIP_ENB_A_C 255 0 255 Specify turning the light ON/OFF in 0~7Chip Forcible Lighting Mode. For Erase Pattern - O O
749-108 LPH_TP5_CHIP_ENB_A_K 255 0 255 Specify turning the light ON/OFF in 0~7Chip Forcible Lighting Mode. For Erase Pattern - O O
749-109 LPH_TP5_CHIP_ENB_B_Y 255 0 255 Specify turning the light ON/OFF in 8~15Chip Forcible Lighting Mode. For Erase Pattern - O O
749-110 LPH_TP5_CHIP_ENB_B_M 255 0 255 Specify turning the light ON/OFF in 8~15Chip Forcible Lighting Mode. For Erase Pattern - O O
749-111 LPH_TP5_CHIP_ENB_B_C 255 0 255 Specify turning the light ON/OFF in 8~15Chip Forcible Lighting Mode. For Erase Pattern - O O
749-112 LPH_TP5_CHIP_ENB_B_K 255 0 255 Specify turning the light ON/OFF in 8~15Chip Forcible Lighting Mode. For Erase Pattern - O O
749-113 LPH_TP5_CHIP_ENB_C_Y 255 0 255 Specify turning the light ON/OFF in 16~23Chip Forcible Lighting Mode. For Erase Pat-
tern
-O O
749-114 LPH_TP5_CHIP_ENB_C_M 255 0 255 Specify turning the light ON/OFF in 16~23Chip Forcible Lighting Mode. For Erase Pat-
tern
-O O
749-115 LPH_TP5_CHIP_ENB_C_C 255 0 255 Specify turning the light ON/OFF in 16~23Chip Forcible Lighting Mode. For Erase Pat-
tern
-O O
749-116 LPH_TP5_CHIP_ENB_C_K 255 0 255 Specify turning the light ON/OFF in 16~23Chip Forcible Lighting Mode. For Erase Pat-
tern
-O O
749-117 LPH_TP5_CHIP_ENB_D_Y 63 0 63 Specify turning the light ON/OFF in 24~29Chip Forcible Lighting Mode. For Erase Pat-
tern
-O O
749-118 LPH_TP5_CHIP_ENB_D_M 63 0 63 Specify turning the light ON/OFF in 24~29Chip Forcible Lighting Mode. For Erase Pat-
tern
-O O
749-119 LPH_TP5_CHIP_ENB_D_C 63 0 63 Specify turning the light ON/OFF in 24~29Chip Forcible Lighting Mode. For Erase Pat-
tern
-O O
749-120 LPH_TP5_CHIP_ENB_D_K 63 0 63 Specify turning the light ON/OFF in 24~29Chip Forcible Lighting Mode. For Erase Pat-
tern
-O O
749-121 LPH_TP5_LIGHT_PATTERN1_Y 170 0 255 Light Pattern 1 of TP5 forcible lighting - O O
749-122 LPH_TP5_LIGHT_PATTERN1_M 170 0 255 Light Pattern 1 of TP5 forcible lighting - O O
Table 1 NVM 749_LPH List
Chain-Link NVM Name
Default
Value
Minimum
value
Maximum
value Description Unit
Write
Allowed/
Protected
Can be
initialized
To Next Page
