05/2014
6-69
DC SC2020
General
6.3.10 NVM 749_LPH List
Version 1.1
749-123 LPH_TP5_LIGHT_PATTERN1_C 170 0 255 Light Pattern 1 of TP5 forcible lighting - O O
749-124 LPH_TP5_LIGHT_PATTERN1_K 170 0 255 Light Pattern 1 of TP5 forcible lighting - O O
749-125 LPH_TP5_LIGHT_PATTERN2_Y 85 0 255 Light Pattern 2 of TP5 forcible lighting - O O
749-126 LPH_TP5_LIGHT_PATTERN2_M 85 0 255 Light Pattern 2 of TP5 forcible lighting - O O
749-127 LPH_TP5_LIGHT_PATTERN2_C 85 0 255 Light Pattern 2 of TP5 forcible lighting - O O
749-128 LPH_TP5_LIGHT_PATTERN2_K 85 0 255 Light Pattern 2 of TP5 forcible lighting - O O
749-130 LPH_PG_SEL 15 0 255 0~3bit: Specify the color to output with Built-in Pattern.
0bit: Y, 1bit: M, 2bit: C, 3bit: K
Do not use the following in ComponentControl.
4~7bit: Perform Built-in PG Overlay Output when printing
4bit: Y Overlay, 5bit: M Overlay, 6bit: C Overlay, 7bit: K Overlay
-O O
749-131 LPH_TP5_LINE 33 0 255 End the forcible lighting after time specified in NVM of component control has passed.
Setting ValueX100msec
100[ms] O O
749-132 LPH_Fail_BYPASS_Y 144 0 255 bit0: LPH Ack Fail, bit1: LPH Read Fail, bit2: LPH_Write_Fail, bit3: LPH_DL_Fail,
bit4: LPH_config_Fail, bit5: LPH_VData_Fail, bit6: LPH_Latch_Fail,
bit7: LPH_ResetDetect_Fail
If each bit is "1", ignore even that Fail generates.
-O O
749-133 LPH_Fail_BYPASS_M 144 0 255 bit0: LPH Ack Fail, bit1: LPH Read Fail, bit2: LPH_Write_Fail, bit3: LPH_DL_Fail,
bit4: LPH_config_Fail, bit5: LPH_VData_Fail, bit6: LPH_Latch_Fail,
bit7: LPH_ResetDetect_Fail
If each bit is "1", ignore even that Fail generates.
-O O
749-134 LPH_Fail_BYPASS_C 144 0 255 bit0: LPH Ack Fail, bit1: LPH Read Fail, bit2: LPH_Write_Fail, bit3: LPH_DL_Fail,
bit4: LPH_config_Fail, bit5: LPH_VData_Fail, bit6: LPH_Latch_Fail,
bit7: LPH_ResetDetect_Fail
If each bit is "1", ignore even that Fail generates.
-O O
749-135 LPH_Fail_BYPASS_K 144 0 255 bit0: LPH Ack Fail, bit1: LPH Read Fail, bit2: LPH_Write_Fail, bit3: LPH_DL_Fail,
bit4: LPH_config_Fail, bit5: LPH_VData_Fail, bit6: LPH_Latch_Fail,
bit7: LPH_ResetDetect_Fail
If each bit is "1", ignore even that Fail generates.
-O O
749-136 LPH_LIFE_CLEAR_ON 0 0 1 Determine whether to clear LPH_LIFE or not when LPH_SERIAL is determined for
replacement.
0: Do not clear, 1: Clear
-O O
749-137 LPH_FAIL_ADDRESS_Y 0 0 32768 Save the accessed IBY address when LPH_ACK_FAIL, READ_FAIL, WRITE_FAIL
occurred. Maximum Value 256kROM => 0x8000
-O O
749-138 LPH_FAIL_ADDRESS_M 0 0 32768 Save the accessed IBY address when LPH_ACK_FAIL, READ_FAIL, WRITE_FAIL
occurred. Maximum Value 256kROM => 0x8000
-O O
749-139 LPH_FAIL_ADDRESS_C 0 0 32768 Save the accessed IBY address when LPH_ACK_FAIL, READ_FAIL, WRITE_FAIL
occurred. Maximum Value 256kROM => 0x8000
-O O
749-140 LPH_FAIL_ADDRESS_K 0 0 32768 Save the accessed IBY address when LPH_ACK_FAIL, READ_FAIL, WRITE_FAIL
occurred. Maximum Value 256kROM => 0x8000
-O O
749-141 LPH_VDATA_CHK 0 0 1 Determine whether to conduct Video Data Interruption Detection Sequence or not.
Perform in the case of 1
-O O
Table 1 NVM 749_LPH List
Chain-Link NVM Name
Default
Value
Minimum
value
Maximum
value Description Unit
Write
Allowed/
Protected
Can be
initialized
To Next Page
