6.3.10 NVM 749_LPH List
Version 1.1
General
749-142 LPH_LATCH_CHK 0 0 1 Determine whether to conduct Video Data Latch Teaming Inspection Sequence or not.
Perform in the case of 1
-O O
749-143 LPH_VDATA_BP0_Y 15 0 15 Black Data Result of OPEN_CHK_DATA0.
Rewrite only when fail occurs with default value 1111. Overwrite if it occurs a multiple
no. of times.
-O O
749-144 LPH_VDATA_BP0_M 15 0 15 Black Data Result of OPEN_CHK_DATA0.
Rewrite only when fail occurs with default value 1111. Overwrite if it occurs a multiple
no. of times.
-O O
749-145 LPH_VDATA_BP0_C 15 0 15 Black Data Result of OPEN_CHK_DATA0.
Rewrite only when fail occurs with default value 1111. Overwrite if it occurs a multiple
no. of times.
-O O
749-146 LPH_VDATA_BP0_K 15 0 15 Black Data Result of OPEN_CHK_DATA0.
Rewrite only when fail occurs with default value 1111. Overwrite if it occurs a multiple
no. of times.
-O O
749-147 LPH_VDATA_BP1_Y 15 0 15 Black Data Result of OPEN_CHK_DATA1.
Rewrite only when fail occurs with default value 1111. Overwrite if it occurs a multiple
no. of times.
-O O
749-148 LPH_VDATA_BP1_M 15 0 15 Black Data Result of OPEN_CHK_DATA1.
Rewrite only when fail occurs with default value 1111. Overwrite if it occurs a multiple
no. of times.
-O O
749-149 LPH_VDATA_BP1_C 15 0 15 Black Data Result of OPEN_CHK_DATA1.
Rewrite only when fail occurs with default value 1111. Overwrite if it occurs a multiple
no. of times.
-O O
749-150 LPH_VDATA_BP1_K 15 0 15 Black Data Result of OPEN_CHK_DATA1.
Rewrite only when fail occurs with default value 1111. Overwrite if it occurs a multiple
no. of times.
-O O
749-151 LPH_VDATA_BP2_Y 15 0 15 Black Data Result of OPEN_CHK_DATA2.
Rewrite only when fail occurs with default value 1111. Overwrite if it occurs a multiple
no. of times.
-O O
749-152 LPH_VDATA_BP2_M 15 0 15 Black Data Result of OPEN_CHK_DATA2.
Rewrite only when fail occurs with default value 1111. Overwrite if it occurs a multiple
no. of times.
-O O
749-153 LPH_VDATA_BP2_C 15 0 15 Black Data Result of OPEN_CHK_DATA2.
Rewrite only when fail occurs with default value 1111. Overwrite if it occurs a multiple
no. of times.
-O O
749-154 LPH_VDATA_BP2_K 15 0 15 Black Data Result of OPEN_CHK_DATA2.
Rewrite only when fail occurs with default value 1111. Overwrite if it occurs a multiple
no. of times.
-O O
749-155 LPH_VDATA_LATCH0_Y 0 0 6 Maximum Value is 6 for No. of failed Data acquiring when VD_LATCH_SEL=0 - O O
749-156 LPH_VDATA_LATCH0_M 0 0 6 Maximum Value is 6 for No. of failed Data acquiring when VD_LATCH_SEL=0 - O O
749-157 LPH_VDATA_LATCH0_C 0 0 6 Maximum Value is 6 for No. of failed Data acquiring when VD_LATCH_SEL=0 - O O
749-158 LPH_VDATA_LATCH0_K 0 0 6 Maximum Value is 6 for No. of failed Data acquiring when VD_LATCH_SEL=0 - O O
Table 1 NVM 749_LPH List
Chain-Link NVM Name
Default
Value
Minimum
value
Maximum
value Description Unit
Write
Allowed/
Protected
Can be
initialized
To Next Page
