05/2014
6-72
DC SC2020
6.3.10 NVM 749_LPH List
Version 1.1
General
749-180 LPH_VDATA_WP2_M 0 0 15 White Data Result of OPEN_CHK_DATA2.
Write over only when Failed with Initial Value0000. Overwrite if it occurs a multiple no. of
times.
-O O
749-181 LPH_VDATA_WP2_C 0 0 15 White Data Result of OPEN_CHK_DATA2.
Write over only when Failed with Initial Value0000. Overwrite if it occurs a multiple no. of
times.
-O O
749-182 LPH_VDATA_WP2_K 0 0 15 White Data Result of OPEN_CHK_DATA2.
Write over only when Failed with Initial Value0000. Overwrite if it occurs a multiple no. of
times.
-O O
749-183 LPH_VD_LATCH_SEL_Y 3 0 7 Store the set value in NVM when Video Data Latch Timing Inspection is conducted.
(00,0110,11)
Set the NVM value to IBY VD_LATCH_SEL Register.
-O O
749-184 LPH_VD_LATCH_SEL_M 3 0 7 Store the set value in NVM when Video Data Latch Timing Inspection is conducted.
(00,0110,11)
Set the NVM value to IBY VD_LATCH_SEL Register.
-O O
749-185 LPH_VD_LATCH_SEL_C 3 0 7 Store the set value in NVM when Video Data Latch Timing Inspection is conducted.
(00,0110,11)
Set the NVM value to IBY VD_LATCH_SEL Register.
-O O
749-186 LPH_VD_LATCH_SEL_K 3 0 7 Store the set value in NVM when Video Data Latch Timing Inspection is conducted.
(00,0110,11)
Set the NVM value to IBY VD_LATCH_SEL Register.
-O O
749-187 LPH_XTALK_CHK 0 0 1 Determine whether to conduct XTALK Detection or not - O O
749-188 LPH_VDATA_CHK_ALL 1 0 1 Determine whether to conduct Video Data Interruption Detection Sequence or not - O O
749-189 Thin Line Correction Switch 0 0 1 The Thin Line Correction Settings ON/OFF Switch
0: Do not correct, 1: Correct
-O O
749-190 Thin Line Correction_ADC_SW 0 0 1 Thin Line Correction Control off Operation
0: Forcible OFF the Thin Line Correction, 1: Do not forcible OFF the Thin Line Correc-
tion
-O O
749-191 Sub-Scanning Direction Patch Size No 1 0 3 Specify the sub-scanning direction size of Cin Determine Window - O O
749-192 Thin Line Correction Low Cin 20 0 110 Saturation Point of Low Cin (L_cin) % O O
749-193 Thin Line Correction High Cin 80 0 110 Saturation Point of High Cin (H_cin) % O O
749-194 Delta density up Y 200 140 255 Thin Line Correction Amount [0.5%] Y Color - O O
749-195 Delta density up M 200 140 255 Thin Line Correction Amount [0.5%] M Color - O O
749-196 Delta density up C 200 140 255 Thin Line Correction Amount [0.5%] C Color - O O
749-197 Delta density up K 200 140 255 Thin Line Correction Amount [0.5%] K Color - O O
749-198 Smile Correction Switch 0 0 1 Smile Correction Setting Switch [ 0: Do not perform, 1: Perform] - O O
749-199 Smile Position Y B 52 1 308 Smile Correction Peak Position Point B (distance from O/B edge) Y Color mm O O
749-200 Smile Position M B 52 1 308 Smile Correction Peak Position Point B (distance from O/B edge) M Color mm O O
749-201 Smile Position C B 52 1 308 Smile Correction Peak Position Point B (distance from O/B edge) C Color mm O O
749-202 Smile Position K B 52 1 308 Smile Correction Peak Position Point B (distance from O/B edge) K Color mm O O
749-203 Smile Position Y C 103 1 308 Smile Correction Peak Position Point C (distance from O/B edge) Y Color mm O O
Table 1 NVM 749_LPH List
Chain-Link NVM Name
Default
Value
Minimum
value
Maximum
value Description Unit
Write
Allowed/
Protected
Can be
initialized
To Next Page
