Fuji Xerox DocuCentre SC2020 Service Manual

05/2014
6-73
DC SC2020
General
6.3.10 NVM 749_LPH List
Version 1.1
749-204 Smile Position M C 103 1 308 Smile Correction Peak Position Point C (distance from O/B edge) M Color mm O O
749-205 Smile Position C C 103 1 308 Smile Correction Peak Position Point C (distance from O/B edge) C Color mm O O
749-206 Smile Position K C 103 1 308 Smile Correction Peak Position Point C (distance from O/B edge) K Color mm O O
749-207 Smile Position Y D 154 1 308 Smile Correction Peak Position Point D (distance from O/B edge) Y Color mm O O
749-208 Smile Position M D 154 1 308 Smile Correction Peak Position Point D (distance from O/B edge) M Color mm O O
749-209 Smile Position C D 154 1 308 Smile Correction Peak Position Point D (distance from O/B edge) C Color mm O O
749-210 Smile Position K D 154 1 308 Smile Correction Peak Position Point D (distance from O/B edge) K Color mm O O
749-211 Smile Position Y E 206 1 308 Smile Correction Peak Position Point E (distance from O/B edge) Y Color mm O O
749-212 Smile Position M E 206 1 308 Smile Correction Peak Position Point E (distance from O/B edge) M Color mm O O
749-213 Smile Position C E 206 1 308 Smile Correction Peak Position Point E (distance from O/B edge) C Color mm O O
749-214 Smile Position K E 206 1 308 Smile Correction Peak Position Point E (distance from O/B edge) K Color mm O O
749-215 Smile Position Y F 257 1 308 Smile Correction Peak Position Point F (distance from O/B edge) Y Color mm O O
749-216 Smile Position M F 257 1 308 Smile Correction Peak Position Point F (distance from O/B edge) M Color mm O O
749-217 Smile Position C F 257 1 308 Smile Correction Peak Position Point F (distance from O/B edge) C Color mm O O
749-218 Smile Position K F 257 1 308 Smile Correction Peak Position Point F (distance from O/B edge) K Color mm O O
749-219 In Out Tendency Y 0 -20 20 The IN OUT Slant Selection Y Color % O O
749-220 In Out Tendency M 0 -20 20 The IN OUT Slant Selection M Color % O O
749-221 In Out Tendency C 0 -20 20 The IN OUT Slant Selection C Color % O O
749-222 In Out Tendency K 0 -20 20 The IN OUT Slant Selection K Color % O O
749-223 Smile Pattern Y 1 1 6 The Smile Correction Pattern Selection Y Color - O O
749-224 Smile Pattern M 1 1 6 The Smile Correction Pattern Selection M Color - O O
749-225 Smile Pattern C 1 1 6 The Smile Correction Pattern Selection C Color - O O
749-226 Smile Pattern K 1 1 6 The Smile Correction Pattern Selection K Color - O O
749-227 Smile Level Y 1 1 6 The Smile Correction Level Selection Y Color
[(Value - 1) x 4%]
-O O
749-228 Smile Level M 1 1 6 The Smile Correction Level Selection M Color
[(Value - 1) x 4%]
-O O
749-229 Smile Level C 1 1 6 The Smile Correction Level Selection C Color
[(Value - 1) x 4%]
-O O
749-230 Smile Level K 1 1 6 The Smile Correction Level Selection K Color
[(Value - 1) x 4%]
-O O
749-231 Smile Custom Y A 0 -20 20 The Smile Custom Correction Ratio Y Color % O O
749-232 Smile Custom M A 0 -20 20 The Smile Custom Correction Ratio M Color % O O
749-233 Smile Custom C A 0 -20 20 The Smile Custom Correction Ratio C Color % O O
749-234 Smile Custom K A 0 -20 20 The Smile Custom Correction Ratio K Color % O O
749-235 Smile Custom Y B 0 -20 20 The Smile Custom Correction Ratio Y Color % O O
749-236 Smile Custom M B 0 -20 20 The Smile Custom Correction Ratio M Color % O O
749-237 Smile Custom C B 0 -20 20 The Smile Custom Correction Ratio C Color % O O
749-238 Smile Custom K B 0 -20 20 The Smile Custom Correction Ratio K Color % O O
Table 1 NVM 749_LPH List
Chain-Link NVM Name
Default
Value
Minimum
value
Maximum
value Description Unit
Write
Allowed/
Protected
Can be
initialized
