Fuji Xerox DocuCentre SC2020 Service Manual

05/2014
6-75
DC SC2020
General
6.3.10 NVM 749_LPH List
Version 1.1
749-268 LPH_YMC_INHIBIT_TRANS_ON 0 0 1 If LPH_YMC_INHIBIT_TRANS_ON (NVM) = 1, to stop the transmission of IBY of YMC
during Single K Print, put INHIBIT_TRANS to 1 (ON).
If LPH_YMC_INHIBIT_TRANS_ON (NVM) = 0, to not stop the transmission of IBY of
YMC during Single K Print, put INHIBIT_TRANS to 0 (OFF).
0: Transmit with YMC, 1: Do not transmit with YMC
-O O
749-269 LPH_WARM_ON 0 0 1 0: Do not perform default value, Heat Cycle
1: Perform Heat Cycle
-O O
749-270 LPH_WARM_WAIT 10 0 255 Unit: 100msec, Default Value: 10 (1.0 sec) 100[ms] O O
749-271 LPH_PG_MODE_Y 1 0 7 PATTERN GENERATER MODE
Select TP1~6 ON/OFF.
-O O
749-272 LPH_PG_MODE_M 1 0 7 PATTERN GENERATER MODE
Select TP1~6 ON/OFF.
-O O
749-273 LPH_PG_MODE_C 1 0 7 PATTERN GENERATER MODE
Select TP1~6 ON/OFF.
-O O
749-274 LPH_PG_MODE_K 1 0 7 PATTERN GENERATER MODE
Select TP1~6 ON/OFF.
-O O
749-275 LPH_SMILE_USHAPE_ON 6 0 255 Switches the ON/OFF for usage in IOT for Light Amount Correction Function of IBY.
bit0: NotUsed
bit1: Specify whether to conduct USHAPE Correction SW, Ushapa Correction or not
bit2: Specify whether to mirror image invert the Ushape Correction of Even Number Chip
bit3: NotUsed
bit4~bit5: SW to select CRATIO_THERM_SEL
bit6~bit7: NotUsed
-O O
749-276 LPH_CRATIO_THERM_SEL 0 0 255 Select the IBY Vitta Correction Function
0: C_RATIO_CUL_S=CRATIO_SIGN
1: Integer part of C_RATIO_CUL_S =THERM_DELTA * THERM_K/64
2, 3: C_RATIO_CUL_S =NOD_LIGHTON_NUM[7: 0] * XTALK_M[7: 0]/64 Integer Part
-O O
749-332 LPH_UC_Y 650 0 2047 Coefficient to use when deriving USHAPE_A[0](calculation value), USHAPE_B[0](calcu-
lation value)
-O O
749-333 LPH_UC_M 650 0 2047 Coefficient to use when deriving USHAPE_A[0](calculation value), USHAPE_B[0](calcu-
lation value)
-O O
749-334 LPH_UC_C 650 0 2047 Coefficient to use when deriving USHAPE_A[0](calculation value), USHAPE_B[0](calcu-
lation value)
-O O
749-335 LPH_UC_K 650 0 2047 Coefficient to use when deriving USHAPE_A[0](calculation value), USHAPE_B[0](calcu-
lation value)
-O O
749-336 LPH_OUT_LOCAL_OFFSET_Y 0 0 2047 Comparison reference value with LPH_OUT_LOCAL. - O O
749-337 LPH_OUT_LOCAL_OFFSET_M 0 0 2047 Comparison reference value with LPH_OUT_LOCAL. - O O
749-338 LPH_OUT_LOCAL_OFFSET_C 0 0 2047 Comparison reference value with LPH_OUT_LOCAL. - O O
749-339 LPH_OUT_LOCAL_OFFSET_K 0 0 2047 Comparison reference value with LPH_OUT_LOCAL. - O O
749-428 LPH_HSYNC_BLANK 19 0 255 Interval of 1 Line Lap (usec)
Idle Period=(LPH_HSYNC_BLANK+1)/10
0.1~25.5usec
-O O
Table 1 NVM 749_LPH List
Chain-Link NVM Name
Default
Value
Minimum
value
Maximum
value Description Unit
Write
Allowed/
Protected
Can be
initialized
