Fuji Xerox DocuCentre SC2020 Service Manual

05/2014
6-76
DC SC2020
6.3.10 NVM 749_LPH List
Version 1.1
General
749-429 HSYNC Fixed Mode 0 0 255 When changing the Process Speed,
0: Set the Calculation Value to IBY.
1: Set the NVM Value to IBY.
-O O
749-430 SOS_CYC_E0 30787 0 1048575 Setting Value of SOS Lap when light comes on during half speed - O O
749-431 SOS_CYC_E1 15393 0 1048575 Setting Value of SOS Lap when light comes on during full speed - O O
749-432 LPH_DOT_NUM_E0 32 10 255 Sets to IBY Register DOT_NUM when changing the process speed. (During half speed)
(When light goes on forcibly)
-O O
749-433 LPH_DOT_NUM_E1 16 10 255 Sets to IBY Register DOT_NUM when changing the process speed. (During full speed)
(When light goes on forcibly)
-O O
749-434 LPH_DOT_NUM_SUB_E0 173 0 255 Sets to IBY Register DOT_NUM_SUB when changing the process speed.
(When light goes on forcibly)(During half speed)
-O O
749-435 LPH_DOT_NUM_SUB_E1 36 0 255 Sets to IBY Register DOT_NUM_SUB when changing the process speed.
(When light goes on forcibly)(During full speed)
-O O
749-436 LPH_HSYNC_CYCLE_E0 8466 0 65535 Sets to IBY Register HSYNC_CYC_H,L when changing the process speed.
(When light goes on forcibly)(During half speed)
-O O
749-437 LPH_HSYNC_CYCLE_E1 4233 0 65535 Sets to IBY Register HSYNC_CYC_H,L when changing the process speed.
(When light goes on forcibly)(During full speed)
-O O
749-438 LPH_VDATA_CHK_COLOR 3 0 3 When conducting Video Data Interruption Detection Sequence for 1 color, store the last
color.
0: Y, 1: M, 2: C, 3: K
-O O
749-439 LPH_FAIL_LATCH_PRIORITY 27 0 255 Priority when there is multiple Latch Timing which was not determined as Fail/
Priority: bit0, 1
2nd Priority: bit2, 3
3rd Priority: bit4, 5
4th Priority: bit6, 7
3, 2, 1, 0 in the order of (default Value 11, 10, 01, 00)
= > 00 01 10 11 => 1B
-O O
749-440 LPH_YMC_INH_FAIL 0 0 1 0: The IBY Register accessed by this operation is not subject to read, write, ack Fail.
(Target Fail does not generate)
1: The IBY Register accessed by this operation is subject to read, write, ack Fail. (Target
Fail generates)
-O O
749-441 LPH_YMC_INHIBIT_TRANS_GAP 0 0 1 0: Do not switch the INHIBIT_TRANCE setting to YMC to by Page when Single K Print.
(Initial Value)
1: Switch the INHIBIT_TRANCE setting to YMC to by Page when Single K Print.
-O O
749-442 LPH_PG_SEL_LM1 4 0 4 Color setting when printing in DC612 LPH Vitta Evaluation Chart (LM1)
0: Single Color Y, 1: Single Color M, 2: Single Color C, 3: Single Color K, 4: FC
-O O
Table 1 NVM 749_LPH List
Chain-Link NVM Name
Default
Value
Minimum
value
Maximum
value Description Unit
Write
Allowed/
Protected
Can be
initialized
