05/2014
6-89
DC SC2020
General
6.3.12 NVM 751_Xero/Clean 2 List
Version 1.1
751-305 #C Recovery Band Cin 90 0 100 0 = 0%, 100 = 100%, Setting is in the increments of 10% (round down 0~9) % O O
751-306 #K Recovery Band Cin 90 0 100 0 = 0%, 100 = 100%, Setting is in the increments of 10% (round down 0~9) % O O
751-307 #Y Recovery Band Length 40 0 50 Recovery Band Length mm O O
751-308 #M Recovery Band Length 40 0 50 Recovery Band Length mm O O
751-309 #C Recovery Band Length 40 0 50 Recovery Band Length mm O O
751-310 #K Recovery Band Length 40 0 50 Recovery Band Length mm O O
751-311 Recovery VH Adjustment Value 0 -1024 1023 Adjust in VH calculated in Procon specification V O O
751-312 Drum Cartridge M/C Operation Switching 0 0 15 M/C Operation switch in Life End/Dead End - O O
751-313 Drum Cartridge Life Determination SW 0 0 1 0: Determine No. of Cycle, 1: Determine PV - O O
751-314 Drum Cartridge Life Determination Threshold
Value SW
0 0 1 0: Refer to CRUM, 1: Refer to NVM - O O
751-315 #Y Life End Film Thickness Threshold Value 13600000 0 30000000 The Drum film thickness threshold value that indicates Life End pm O O
751-316 #M Life End Film Thickness Threshold Value 13600000 0 30000000 The Drum film thickness threshold value that indicates Life End pm O O
751-317 #C Life End Film Thickness Threshold Value 13600000 0 30000000 The Drum film thickness threshold value that indicates Life End pm O O
751-318 #K Life End Film Thickness Threshold Value 13600000 0 30000000 The Drum film thickness threshold value that indicates Life End pm O O
751-319 #Y Dead End Film Thickness Threshold Value 9000000 0 30000000 The Drum film thickness threshold value that indicates Dead EndpmOO
751-320 #M Dead End Film Thickness Threshold Value 9000000 0 30000000 The Drum film thickness threshold value that indicates Dead EndpmOO
751-321 #C Dead End Film Thickness Threshold Value 9000000 0 30000000 The Drum film thickness threshold value that indicates Dead EndpmOO
751-322 #K Dead End Film Thickness Threshold Value 9000000 0 30000000 The Drum film thickness threshold value that indicates Dead EndpmOO
751-323 #Y Delta Pre Near Film Thickness Threshold
Value
168000 0 30000000 The Drum film thickness threshold value between Pre Near and Life End pm O O
751-324 #M Delta Pre Near Film Thickness Threshold
Value
168000 0 30000000 The Drum film thickness threshold value between Pre Near and Life End pm O O
751-325 #C Delta Pre Near Film Thickness Threshold
Value
168000 0 30000000 The Drum film thickness threshold value between Pre Near and Life End pm O O
751-326 #K Delta Pre Near Film Thickness Threshold
Value
168000 0 30000000 The Drum film thickness threshold value between Pre Near and Life End pm O O
751-327 #Y Delta Near Film Thickness Threshold Value 50400 0 30000000 The Drum film thickness threshold value between Near and Life End pm O O
751-328 #M Delta Near Film Thickness Threshold Value 50400 0 30000000 The Drum film thickness threshold value between Near and Life End pm O O
751-329 #C Delta Near Film Thickness Threshold Value 50400 0 30000000 The Drum film thickness threshold value between Near and Life End pm O O
751-330 #K Delta Near Film Thickness Threshold Value 50400 0 30000000 The Drum film thickness threshold value between Near and Life End pm O O
751-331 #Y Life End Cycle Threshold Value 7000 0 65535 The Drum Cycle threshold value that indicates Life End 100[Cycle] O O
751-332 #M Life End Cycle Threshold Value 7000 0 65535 The Drum Cycle threshold value that indicates Life End 100[Cycle] O O
751-333 #C Life End Cycle Threshold Value 7000 0 65535 The Drum Cycle threshold value that indicates Life End 100[Cycle] O O
751-334 #K Life End Cycle Threshold Value 7000 0 65535 The Drum Cycle threshold value that indicates Life End 100[Cycle] O O
751-335 #Y Dead End Cycle Threshold Value 10830 0 65535 The Drum Cycle threshold value that indicates Dead End 100[Cycle] O O
751-336 #M Dead End Cycle Threshold Value 10830 0 65535 The Drum Cycle threshold value that indicates Dead End 100[Cycle] O O
751-337 #C Dead End Cycle Threshold Value 10830 0 65535 The Drum Cycle threshold value that indicates Dead End 100[Cycle] O O
751-338 #K Dead End Cycle Threshold Value 10830 0 65535 The Drum Cycle threshold value that indicates Dead End 100[Cycle] O O
Table 1 NVM 751_Xero/Clean 2 List
Chain-Link NVM Name
Default
Value
Minimum
value
Maximum
value Description Unit
Write
Allowed/
Protected
Can be
initialized
To Next Page
